Description
Major Product Feature:
· 100-240Vac Universal Input Voltage –
· Nominal Efficiency>=88% –
· Aluminum case surface temperature at full load less than 45 degree –
· Charging process fully controlled by Microprocessor –
· High Frequency system with advanced technology Output Boost Charge Voltage (Sealed lead acid batteries 2.40V/cell) 14.4V Boost Charge Voltage (Flooded lead acid batteries 2.65V/cell) 15.9V Boost Charge Voltage (Li-ion batteries 4.2V/cell) 16.8V (4 cells) Boost Charge Voltage (LiFeO4 batteries 3.6V/cell) 14.4 (4 cells) Battery Type Support for Typical Lead acid & GEL / Flooded batteries/ Lithium-ion / LiFeO4 Output Voltage / Current 12V12A 12V15A INPUT Voltage Range 100 ~ 240VAC Frequency Range (Typical) 47 ~ 63Hz Protection Output short YES Reversed Polarity YES Over Temperature YES Sparkless protection YES Function Cooling system with low current fan Temperture Sense by NTC Environment Working Temperature ( -10℃ ~ 45℃ ) Storage Temperature -10℃ ~ 70℃ Vibration 10~500Hz, 2G 10min/1 cycle, 60 min. each along X,Y,Z axes Safety & EMC Safety Standard EN60335-2-29 EMC EN55014 CLASS B Others
DIMENSION L165 X W95 X H55MM
Weight exclude the AC cord 0.8KGS MTBF ≥15Khour on the test condition of 25C
full load Connector AC PLUG DC cable & output connector
